Our Crafts

ROBUS 30 CASEMENT WINDOWS

Product Range of Typologies

Frame Info

Frame Face Width: 44mm
Frame Depth: 48mm, 74mm, 84mm
Sash Face Width: 53mm
Sash Depth: 26mm
Wall Thickness: Min 1.2mm
Glass Thickness: 5mm to 8mm
Interlock Face width: 32mm

Hardware

Hardware: Aluminium/
Stainless steel

Single Locking Systems

Specifiacations

Wind Load Resistance


Designed for 1500 pa



Air Permeability


Designed for 300 pa



Water Tightness


Designed for 200 pa

Sash Info

Sash Minimum


600mm (H) x 500mm (W)



Sash Size Maximum


1500mm (H) x 800mm (W)


Max per sash weight

30 Kg
Non Concealed

The Robus 30 Windows are a perfect union of minimalist design and robust performance, created for spaces that demand both refined aesthetics and everyday functionality. With its carefully balanced aluminium profile, Robus 30 offers slim sightlines that flood interiors with natural light while maintaining exceptional structural strength.

Designed for modern living, these windows elevate any architectural style — from contemporary urban homes to sophisticated commercial projects. The clean, linear design frames views with subtlety, ensuring the outside world remains the star, while the durable aluminium construction guarantees lasting beauty with minimal maintenance.

Beyond its elegant appearance, Robus 30 is built to perform. Its precision sealing offers excellent thermal insulation, helping maintain interior comfort while improving energy efficiency. Advanced soundproofing features create a peaceful indoor environment, even in busy urban settings.

Smooth operation, high-quality hardware, and multi-point locking systems ensure security, reliability, and ease of use, making Robus 30 an ideal choice for discerning homeowners and architects alike.

“Robus 30 — Framing Light, Defining Strength”

Graf 26 Sliding Doors

Frame Info

Frame Face Width: 44mm
Frame Depth: 48mm, 74mm, 84mm
Sash Face Width: 53mm
Sash Depth: 26mm
Wall Thickness: Min 1.2mm
Glass Thickness: 5mm to 8mm
Interlock Face width: 32mm

Specifiacations

Wind Load Resistance


Designed for 1500 pa



Air Permeability


Designed for 300 pa



Water Tightness


Designed for 200 pa

Hardware

Hardware: Aluminium/
Stainless steel

Multi Point Locking Systems

Sash Info

Sash Minimum
600mm (H) x 500mm (W)

Sash Size Maximum
2100mm (H) x 1000mm (W)



Max per sash weight 50 Kg
Non Concealed

Offering a solid design for windows and doors up to 2.4 meters, emphasizing visible frame aesthetics and enhanced sturdiness. With a 40mm frame depth and multipoint locking system for superior security and sealing, it supports double-glazing up to 28mm and includes features like injection-molded corner gaskets and a central seal gasket for improved insulation.

Offering a solid design for windows and doors up to 2.4 meters, emphasizing visible frame aesthetics and enhanced sturdiness. With a 40mm frame depth and multipoint locking system for superior security and sealing, it supports double-glazing up to 28mm and includes features like injection-molded corner gaskets and a central seal gasket for improved insulation.

Offering a solid design for windows and doors up to 2.4 meters, emphasizing visible frame aesthetics and enhanced sturdiness. With a 40mm frame depth and multipoint locking system for superior security and sealing, it supports double-glazing up to 28mm and includes features like injection-molded corner gaskets and a central seal gasket for improved insulation.
